Single-sided print module
∙ Color sublimation directly on the card and resin thermal
transfer
∙ Rewritable card printing
∙ Print resolution:
– In color and monochrome: 300×300 dpi & 300×600 dpi
– In monochrome: up to 300×1200 dpi
∙ Print optimization via color profile
∙ Interface: LED panel
Everything you need is in Zenius 2,
The ingenuity of Zenius 2 lies in its ability to do the
essentials and do them well. It meets your small
or medium-run printing needs with efficient and
well-designed features.
Single-sided printing, color or monochrome,
professional print quality, encoding option…
All in a lightweight, compact product:
discover Zenius 2.
| printing |
Single Sided |
|---|---|
| Encoding |
Magnetic stripes encoding kit ,No Encoding option |
| Card Lifespan |
1-3 years |
Designed for a comprehensive
user experience
Zenius 2 is as ingenious as it is intuitive, offering
a comprehensive user experience.
The printer is easy to use thanks to its smart design:
a 50-card feeder, a card-by-card insertion slot, an output
hopper for up to 50 cards, and easy access to the ribbon.
At the same time, its comprehensive software suite
makes it easy to create and print your cards. It includes
an optimized driver for Windows and Mac and ID-ALL
card creation software.
Multiple printing features
• Edge-to-edge printing, single side
• Color sublimation / monochrome thermal transfer
• Rewrite technology for rewritable cards
High-performance printing and autonomy
• Color printing up to 180 cards/hour
• Monochrome printing up to 700 cards/hour
• Automatic 50 card feeder
• 25 and 50 card output hopper
• Card-by-card loading option
• Color adjustment via color profile
Security of issued cards and data
• Multiple encoding options*
• Printing of UV effect*
• Double layer overlay*
• Data deletion with digital erasing
Intuitive use
• Evolis Premium Suite with optimized user experience
on Windows & Mac
• USB impression
• Network use*
• Printing from smartphone and tablet
• Card personalization software
Reliability
• Print head with reinforced protection
Sleek design
• Timeless, elegant design
• Compact and lightweight
Technical Specifications
GENERAL FEATURES
∙ Single-sided print module
∙ Color sublimation directly on the card and resin thermal
transfer
∙ Rewritable card printing
∙ Print resolution:
– In color and monochrome: 300×300 dpi & 300×600 dpi
– In monochrome: up to 300×1200 dpi
∙ Print optimization via color profile
∙ Interface: LED panel
PRINT SPEED
∙ Single-sided, color: up to 180 cards/hour
∙ Single-sided, monochrome: up to 700 cards/hour
CARD MANAGEMENT AND SPECIFICATIONS
∙ Automatic or manual feeder
∙ Feeder capacity: 50 cards (0.76 mm – 30 mil)
∙ Front output hopper capacity: 25 cards (0.76 mm – 30 mil)
∙ Back output hopper capacity: 50 cards (0.76 mm – 30 mil)
∙ Card thickness: 0.25 to 0.76 mm (10 to 30 mil), adjustment
using the gauge
∙ Types of cards: PVC cards, composite PVC cards, PET cards*,
paper cards* and rewritable cards
∙ Card format: ISO CR80 – ISO 7810
(53.98 mm x 85.60 mm)
PORTS/CONNECTIVITY
∙ USB 2.0 (compatible with 1.0 and 3.0), cable included
∙ Ethernet TCP-IP 10BaseT, 100BaseT (Traffic Led) on Expert
version
EVOLIS HIGH TRUST® RIBBONS
To maximize the quality and lifetime of the printed cards, the
service life of the print head, and the overall reliability of your
printer, use Evolis High Trust® ribbons.
∙ Automatic recognition and setup
∙ Ribbon cassettes for one-step installation or an EASY4PRO
offer without cassette for users who want to reduce their
environmental impact.
– YMCKO: 200 prints per roll
– ½ YMCKO: 400 prints/roll
– YMCKOO: 250 prints per roll
– Black monochrome: 2,000 prints per roll
(under certain conditions)
SECURITY
∙ Kensington® security lock
∙ Print head protection during maintenance or ribbon
changes
∙ Erasing sensitive data from the printer memory
∙ UV effect printing with YMCKOO ribbon in Expert version
ENCODING MODULES
– Magnetic stripe encoder ISO 7811
– Contact smartcard encoders
– Contactless smartcard encoders
– Dual smartcard encoders (contact / contactless)
∙ Options can be combined
∙ Factory or on-site installation
