Specifications

Printer specifications
Print technology
Dye-sublimation, direct-to-card
Rewritable
Print resolution
300 dpi
Print area
53.98 x 85.6mm / 3.370’’ x 2.125’’ (CR-80 cards)
Print speed
• 150 cph (YMCKO single-side)
• 700 cph (monochrome printing)
Print mode
Single-sided / optional dual-sided
Printer memory
128 Mb
Communications interface
USB 2.0
Easy to use, plug and print operation
• 4 x LED status indicators
• Full front operation
• Drop in ribbon cassette with easy handling
• Automatic ribbon identification and setting
• Easy reach power button
• Easy maintenance access
Printer security
Support for Kensington® security lock
Printer dimensions (HxWxD)
256 x 202 x 405 mm / 10.6” x 7.9” x 15.9”
Weight
5.9 kg, 13 lb
Power supply
• 220-240V/110-115V, 50-60 Hz
• Standby mode and reduced power consumption
Operating environment
• Temperature: 15ºC – 40ºC, 59ºF – 104ºF
• Humidity: 20% – 65% (non-condensing)
Storage conditions
• Temperature: 5ºC to 70ºC, 23ºF to 158ºF
• Humidity: 20% to 70% (non-condensing)
Sound (ISO 7779)
Sound pressure less than 48dB (A)
Certifications
RoHs, CE, FCC, CQC, UL, WEEE, Proposition 65
(California, USA), Radio Equipment Directive (RED)
(2014/53/EU)
Warranty
1year (subject to the use of chromXpert® ribbons)
Card specifications
Input hopper capacity
100 cards (0.76 mm / 30 mil thickness)
Output hopper capacity
30 cards (front)
Card thickness
• 0.25 mm – 1.25 mm / 10 mil – 50 mil
• Gauge adjustment
Card types
CR-80 PVC, PVC-C
Software specifications
XPS printer driver
Windows® (32/64bit) 7, 8.1, 10, 11, Server 2012,
2016, 2019, 2022
MacOS
MacOS: from Mavericks 10.9 to Ventura 13.1
Options
Smart card / contactless encoding
• Contact PC/SC, EMV compliant
• Smart contact station: ISO 7816-2
• ISO14443A, B, ISO15693, MIFARE®, DESFire®,
HID iClass®
Dual-side activation kit PR10300016
